MJW1216AT052 / MJW1216AT
Wedge Brakes
Piston - Parking Brakes
Breather Tube
Stock Status: Made to order
Lead Time: 21 days
Price: $763.43
Service Size: 12
Spring Size: 16
Specs
Aftermarket Unit
Mounting Bolt Thread: 1 3/4-12 UN-2A
Mounting Bolt Length (in.): 1.519
Port Size: 3/8-18 NPTF
Tube Length (in.): 2.250 (MERITOR)
Stroke (in.): 1.75
MJW Model Features
- Wide Choice Tube Lengths
- Lightweight, Rugged Aluminum Hosing
- Epoxy-Coated Power Spring
- External Breather Tube
- Integral Release Bolt
- Polymer Push-Rod Guides
- Molded Nitrile Rubber Push-Rod Air Seal
- Low Friction Piston and Guide
- Heavy Duty Nylon Reinforced Diaphragms
Part Number: MJW1216AT052
Model: MJW1216AT
| Stroke | 1.75" (44.5 mm) |
| Weight lb (kg)* | 12.50 lb (5.7 kg) |
| A | 7.89" (200.4 mm) |
| B | 5.83" (148.1 mm) |
| C | 5.70" (144.8 mm) |
| D | 6.44" (163.6 mm) |
| E | 1 3/4" - 12 UNC |
| Inlets | 3/8" - 18 NPTF |
| *NOTE: | Weight will vary |
Part Number: MJW1216AT052
Model: MJW1216AT
| 1 | Kit -Breather Tube | 9081001 |
| 2 | Kit -Nuts & Bolts | 9003002 |
| 3 | Clamp Band Assembly | 8216012 |
| 4 | Kit -Diaphragm/Push Rod | See Item 10 Kit |
| 5 | Diagphragm | See Item 10 Kit |
| 6 | Rush Rod | See Item 10 Kit |
| 7 | Kit -Wedge Boot | 9004005 |
| 8 | Spanner Nut | 8034007 |
| 9 | Wedge Guide (Meritor) | 8024006 |
| 10 | Kit -NP Chamber - 2.25" Meritor | 9015247 |
| 10 | Kit -NP Chamber - 2.25" Bendix | 9015254 |
| 10 | Kit -NP Chamber - 2.85" Meritor | 9015248 |
| 10 | Kit -NP Chamber - 2.85" Bendix | 9015255 |
| 10 | Kit -NP Chamber - 4.10" Meritor | 9015249 |
| 10 | Kit -NP Chamber - 4.10" Bendix | 9015256 |
| 10 | Kit -NP Chamber - 6.10" Meritor | 9015250 |
| 10 | Kit -NP Chamber - 6.10" Bendix | 9015257 |
Alternate Parts
MJW1216AT053 / MJW1216AT
Disclaimer:
If you are using an aftermarket replacement part number for the replacement of an OEM part number, the port and clamp band angles may need to be rotated and the push rod may need to be cut to length. In addition, our aftermarket part numbers come standard with no yoke assembly.
Replacement parts may differ for production part numbers. If you are uncertain that the replacement part listed will work in your unit, please contact us via Live Chat or by calling customer service at 1-800-527-1534 Ext. 6021.
Images may not be actual configuration.
