MJB2424DT049 / MJB2424DT
Air Disc Brakes
Piston - Parking Brakes
Breather Tube, Welded Mtg Bolts
Stock Status: In Stock
Price: $635.81
Service Size: 24
Spring Size: 24
Specs
Aftermarket Unit
Mounting Bolt Thread: M16 X 1.5
Mounting Bolt Length (in.): 1.710
Port Size: M16 X 1.5
Stroke (in.): 2.50
Magnum Performance Plus Model Features
- Tamper Resistant Design
- Lighter Weight
- Compact Size
- New Patented Integral Release Bolt Mechanism -Minimal Bolt Protrusion (Approx. 1.25 inch (31.8 mm)
- Non-Coil Clash Power Spring
- Increased Corrosion Resistance -Steel Head, Epoxy Coated
- Available With 1,922-2,450 Lbs. (871.8 kg-1111.3 kg) of Push-Rod Braking Force @ 1.25 inch (31.8 mm) Stroke/Service Brake Sizes 16-30
Part Number: MJB2424DT049
Model: MJB2424DT
| Stroke | 2.50" (63.5 mm) |
| Weight lb (kg) Combination | 19.5 lb (8.9 kg) |
| A | 9.88" (250.9 mm) |
| B | 6.74" (171.2 mm) |
| C | 7.38" (187.5 mm) |
| D | 4.75" (120.7 mm) |
| E | M16 x 1.5 - 6g |
| Ports | M16 x 1.5 |
| XB | 15 mm |
Part Number: MJB2424DT049
Model: MJB2424DT
No replacement parts found.
Disclaimer:
If you are using an aftermarket replacement part number for the replacement of an OEM part number, the port and clamp band angles may need to be rotated and the push rod may need to be cut to length. In addition, our aftermarket part numbers come standard with no yoke assembly.
Replacement parts may differ for production part numbers. If you are uncertain that the replacement part listed will work in your unit, please contact us via Live Chat or by calling customer service at 1-800-527-1534 Ext. 6021.
Images may not be actual configuration.
